| Specifications |
|
Position X10
|
|
Attenuation Ratio 10:1 Bandwidth DC to 300MHz. Rise Time 1.16nS. Input Resistance 10MΩ when use with Oscilloscopes which have 1MΩ input; Input Capacitance Approx. 10 pF. Compensation Range 10 to 35pF. Working Voltage 600V CAT I, 300V CAT Ⅱ (DC + peak AC) derating with Frequency. |
|
Position REF
|
| Probe tip grounded via 9MΩ resistor, Oscilloscope input grounded. |
|
Position X1
|
| Attenuation Ratio 1:1
Bandwidth DC to 60MHz. Rise Time 58ns. Input Resistance 1MΩ (Oscilloscope input resistance). Input Capacitance Approx. 47 pF plus Oscilloscope Capacitance. Working Voltage 300V CAT I, 150V CAT Ⅱ (DC + peak AC) derating with Frequency. |
|
Operating Temperature -10C to +55C. Humidity 85% RH or less (at 35C). Safety Meets EN61010-031 CAT Ⅱ. Cable Length 0.8 Meter. |
