Özellikler
|
Specifications |
Range |
Best Accuracy |
|
Model |
|
UT18C |
|
LED AC/DC Voltage Indication (V) |
12V |
8V±2V |
|
24V |
18V±2V |
|
|
50V |
38V±4V |
|
|
120V |
92V±6V |
|
|
230V |
174V±8V |
|
|
400V |
320V±10V |
|
|
690V |
550V±15V |
|
|
Phase Rotation Test |
Operating Voltage: 100V~690V |
√ |
|
Frequency：50Hz~ 60Hz |
||
|
Single Lead(L2)Voltage Detection |
Operating Voltage：100V~690V |
√ |
|
Frequency: 50Hz~ 400Hz |
||
|
Continuity Test |
Resistance: 0~100KΩ |
√ |
|
Beeper and LED light Indicator |
||
|
RCD Test |
Operating Voltage：230V(50Hz～400Hz) |
√ |
|
Polarity Detection |
Positive & Negative |
√ |
|
Self-inspection |
All LED or LCD indicator |
√ |
|
No Power Test |
Operating Voltage: 50VAC/120VDC~690VDC/AC |
√ |
|
Features |
||
|
IP65 |
|
√ |
|
Auto Range |
All Range |
√ |
|
Exceed Voltage |
Voltage Range：713V～788V |
√ |
|
Auto standby |
standby current <10uA |
√ |
|
Silent mode |
All Range |
√ |
|
Work Light |
All Range |
√ |
|
Low Battery Indication |
Voltage Range：2.2V～2.4V |
√ |
|
LCD Display (Voltage+frequency) |
6V~ 690V (40Hz～400Hz) |
±(1.5%+5) |
